SLRM-P10

SLRM-P10 is a high-performance, multi-protocol radio module built around the advanced Texas Instruments CC2674P10 wireless SoC. Designed for demanding IoT, smart home, and industrial automation applications, the module combines powerful wireless connectivity with ultra-low power operation and flexible GPIO configuration. Supporting Bluetooth® LE, Zigbee®, Thread, and IEEE 802.15.4, the SLRM-P10 is ideal for developers seeking a compact and future-proof RF module with robust RF output and versatile integration options.

At its core, the CC2674P10 features a powerful 48 MHz ARM® Cortex®-M33 core, integrated power amplifier (up to +20 dBm output), hardware crypto engine, and ample memory resources — including up to 1 MB Flash and 296 KB RAM — making SLRM-P10 suitable for secure, scalable, and high-throughput wireless communication.

With a compact footprint based on the SLMRv1 platform, SLRM-P10 ensures effortless replacement or upgrade in space-constrained designs.

General

• Module Name: SLMR-P10
• SoC: Texas Instruments CC2674P10
• Core MCU: 32-bit ARM® Cortex®-M33 @ 48 MHz
• Core Voltage: 1.8–3.8 V
• Operating Temperature Range: –40°C to +85°C (industrial grade)
• Package Type: Stamp-hole SMT module
• Pin Pitch: 1.27 mm
• Dimensions: 16.4 × 27.0 × 2.7 mm (SLRMv1 sizing platform)

Wireless Features

• Radio Frequency: 2.4 GHz ISM band
• Supported Protocols:Bluetooth® Low Energy 5.3 (LE Audio Ready)Zigbee® 3.0Thread (including Matter over Thread)IEEE 802.15.4
• Bluetooth® Low Energy 5.3 (LE Audio Ready)
• Zigbee® 3.0
• Thread (including Matter over Thread)
• IEEE 802.15.4
• Output Power: Up to +20 dBm (with integrated PA)
• RX Sensitivity: Up to –104 dBm (BLE 1 Mbps)
• Range: Up to 600+ meters (open space, BLE)
• Modulations:BLE: GFSK802.15.4: O-QPSK
• BLE: GFSK
• 802.15.4: O-QPSK

Performance & Memory

• Flash: Up to 1 MB
• RAM: 256 KB
• ROM (bootloader and libraries): Yes, integrated
• Non-volatile Storage: Support via Flash sectoring

Security

• Secure Boot: Yes
• Hardware Crypto Accelerator: AES-128/256, ECC, SHA-2
• Key Storage: Secure Key Storage (KSR)
• TRNG: True Random Number Generator
• Arm TrustZone®: Supported

I/O and Peripherals

• GPIOs: Up to 31 (multiplexed)
• Analog Interfaces:8-channel 12-bit ADC2 × DAC (digital-to-analog converter)
• 8-channel 12-bit ADC
• 2 × DAC (digital-to-analog converter)
• Timers:4 × General-purpose timers1 × RTC with calendar
• 4 × General-purpose timers
• 1 × RTC with calendar
• Interfaces:UART: Up to 2SPI: Up to 2I²C: Up to 2PWM: Multiple (via Timer)QDEC: Quadrature DecoderDebug Interface: SWD, JTAG compatible
• UART: Up to 2
• SPI: Up to 2
• I²C: Up to 2
• PWM: Multiple (via Timer)
• QDEC: Quadrature Decoder
• Debug Interface: SWD, JTAG compatible

Power Management

• Transmit Current (@ +20 dBm): ~ 13.7 mA
• Receive Current: ~ 6.9 mA
• Deep Sleep Current: ~ 500 nA
• Power Modes:ActiveIdleStandbyShutdown
• Active
• Idle
• Standby
• Shutdown
